WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

G31.41+0.31
RA: 18 47 34.3 (^{h m s})
Dec: -1 12 46.01 (^{o ' "})

Observation Details

OBSID: 1342191671
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP1_H2O 111-000 - G31.41+0.31
Band: 4B
Herschel Operation Day: OD295
Integration Time: 489 sec
LO Frequency: 1108.035 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-03-04
HSA Processing Date: 2014-07-15
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.63
Beam Efficiency V⁽¹⁾: η=0.64
Beam Efficiency (2012) ⁽¹⁾: η=0.737
Position offset (x,y): (0,0) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0816	0.0938
continuum (K)	1.785	1.624

Downloads Corner

• RAW HIPE FORMAT (106MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Van der Tak et al. 2013, A&A
San Jose-Garcia et al. 2013, A&A
Wyrowski et al. 2010, A&A
Marseille et al. 2010, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
