WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

NGC1333 IRAS2
RA: 3 28 55.6 (^{h m s})
Dec: 31 14 36.96 (^{o ' "})

Observation Details

OBSID: 1342191606
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: SDP_H2O 202-111 - NGC1333 IRAS2
Band: 4A
Herschel Operation Day: OD293
Integration Time: 1217 sec
LO Frequency: 745.992 GHz
HIPE/Pipeline Version: SPG v11.1.0
Observation Date: 2010-03-03
HSA Processing Date: 2014-01-24
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.64
Beam Efficiency V⁽¹⁾: η=0.66
Beam Efficiency (2012) ⁽¹⁾: η=0.749
Position offset (x,y): (0,0) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0395	0.0478
continuum (K)	0.249	0.219

Downloads Corner

• RAW HIPE FORMAT (105MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Suutarinen et al. 2014, MNRAS
Mottram et al. 2014, A&A
Van Dishoeck et al. 2013, ChRv
Visser et al. 2013, ApJ
Kristensen et al. 2013, A&A
Yildiz et al. 2013A, A&A
San Jose-Garcia et al. 2013, A&A
van Dishoeck et al. 2011, PASP
Yildiz et al. 2010, A&A
Kristensen et al. 2010, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
