WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

W43-MM1
RA: 18 47 47.0 (^{h m s})
Dec: -1 54 28.01 (^{o ' "})

Observation Details

OBSID: 1342192345
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP1_H2O-17 110-101 - W43-MM1
Band: 1A
Herschel Operation Day: OD310
Integration Time: 189 sec
LO Frequency: 546.246 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-03-19
HSA Processing Date: 2014-07-15
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (0,0) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0264	0.0267
continuum (K)	0.533	0.560

Downloads Corner

• RAW HIPE FORMAT (89MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Herpin et al. 2012, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
