WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

DR21-OH
RA: 20 39 0.7 (^{h m s})
Dec: 42 22 48.00 (^{o ' "})

Observation Details

OBSID: 1342192361
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP1_H2O-17 110-101 - DR21-OH
Band: 1A
Herschel Operation Day: OD310
Integration Time: 208 sec
LO Frequency: 546.23475 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-03-20
HSA Processing Date: 2014-07-15
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (0,0) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0296	0.0246
continuum (K)	0.691	0.647

Downloads Corner

• RAW HIPE FORMAT (89MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
