WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

AS209
RA: 16 49 15.4 (^{h m s})
Dec: -14 22 8.76 (^{o ' "})

Observation Details

OBSID: 1342192518
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP2_H2O 110-101 - AS209
Band: 1B
Herschel Operation Day: OD311
Integration Time: 1881 sec
LO Frequency: 564.78375 GHz
HIPE/Pipeline Version: SPG v11.1.0
Observation Date: 2010-03-21
HSA Processing Date: 2014-01-24
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (0,0) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0070	0.0089
continuum (K)	0.004	0.003

Downloads Corner

• RAW HIPE FORMAT (117MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
