WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

DR21-OH
RA: 20 39 0.7 (^{h m s})
Dec: 42 22 48.00 (^{o ' "})

Observation Details

OBSID: 1342194794
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP1_H2O 111-000 - DR21-OH
Band: 4B
Herschel Operation Day: OD338
Integration Time: 601 sec
LO Frequency: 1107.954 GHz
HIPE/Pipeline Version: SPG v11.1.0
Observation Date: 2010-04-17
HSA Processing Date: 2014-01-24
WISH Processing Date: 2014-08-01
Beam Efficiency H ⁽¹⁾: η=0.63
Beam Efficiency V⁽¹⁾: η=0.64
Beam Efficiency (2012) ⁽¹⁾: η=0.737
Position offset (x,y): (0.009037,0.577048) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0678	0.0826
continuum (K)	3.586	3.590

Downloads Corner

• RAW HIPE FORMAT (106MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Indriolo et al. 2015, ApJ
Van der Tak et al. 2013, A&A
Wyrowski et al. 2010, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
