WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

L1157
RA: 20 39 6.2 (^{h m s})
Dec: 68 2 15.72 (^{o ' "})

Observation Details

OBSID: 1342198346
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: KPGT_evandish_1-CO 10-9 - L1157 - resched
Band: 5A
Herschel Operation Day: OD398
Integration Time: 1104 sec
LO Frequency: 1146.8655 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-06-15
HSA Processing Date: 2014-07-17
WISH Processing Date: 2014-08-01
Beam Efficiency H ⁽¹⁾: η=0.59
Beam Efficiency V⁽¹⁾: η=0.59
Beam Efficiency (2012) ⁽¹⁾: η=0.638
Position offset (x,y): (-0.77925,-2.5546) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.1489	0.1744
continuum (K)	0.037	0.055

Downloads Corner

• RAW HIPE FORMAT (99MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Mottram et al. 2014, A&A
Mottram et al. 2013, A&A
Yildiz et al. 2013A, A&A
San Jose-Garcia et al. 2013, A&A
Vasta et al. 2012, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
