WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

W3 IRS5
RA: 2 25 40.6 (^{h m s})
Dec: 62 5 51.00 (^{o ' "})

Observation Details

OBSID: 1342201531
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: SDP_W3 IRS5 - Setting 16 - shift
Band: 1B
Herschel Operation Day: OD429
Integration Time: 1234 sec
LO Frequency: 611.973 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-07-17
HSA Processing Date: 2014-07-22
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.752
Position offset (x,y): (6.81379,-0.37934) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0104	0.0124
continuum (K)	0.403	0.398

Downloads Corner

• RAW HIPE FORMAT (105MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Indriolo et al. 2015, ApJ

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
