WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

W3-IRS5
RA: 2 25 40.6 (^{h m s})
Dec: 62 5 51.00 (^{o ' "})

Observation Details

OBSID: 1342203160
Obs. Type: HIFI Mapping
Obs. Mode: OTF - Position Switch
AOR Label: HMap -987- W3-IRS5
Band: 4A
Herschel Operation Day: OD461
Integration Time: 1292 sec
LO Frequency: 747.252 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-08-18
HSA Processing Date: 2014-07-23
WISH Processing Date: 2014-08-23
Beam Efficiency H ⁽¹⁾: η=0.64
Beam Efficiency V⁽¹⁾: η=0.66
Beam Efficiency (2012) ⁽¹⁾: η=0.749
Position offset (x,y): (6.36795,1.13807) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.4509	0.5487
continuum (K)	1.440	1.045

Downloads Corner

• RAW HIPE FORMAT (874MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
