WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

NGC 1333 4B
RA: 3 29 12.0 (^{h m s})
Dec: 31 13 8.04 (^{o ' "})

Observation Details

OBSID: 1342203178
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: NGC1333 IRAS4B - Setting 2
Band: 4A
Herschel Operation Day: OD462
Integration Time: 2902 sec
LO Frequency: 701.9235 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-08-18
HSA Processing Date: 2014-07-23
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.64
Beam Efficiency V⁽¹⁾: η=0.66
Beam Efficiency (2012) ⁽¹⁾: η=0.75
Position offset (x,y): (2.87952,2.20739) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0339	0.0408
continuum (K)	0.176	0.185

Downloads Corner

• RAW HIPE FORMAT (117MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Benz et al. 2015, A&A Submitted

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
