WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

L1448-MM
RA: 3 25 38.9 (^{h m s})
Dec: 30 44 5.28 (^{o ' "})

Observation Details

OBSID: 1342203202
Obs. Type: HIFI Single Point
Obs. Mode: Position Switch
AOR Label: PSP2_H2O 110-101 - L1448-MM
Band: 1B
Herschel Operation Day: OD462
Integration Time: 623 sec
LO Frequency: 562.65525 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-08-19
HSA Processing Date: 2014-07-23
WISH Processing Date: 2014-08-06
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (3.22154,1.09431) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0162	0.0197
continuum (K)	0.027	0.074

Downloads Corner

• RAW HIPE FORMAT (8MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Mottram et al. 2014, A&A
Kristensen et al. 2012, A&A
Kristensen et al. 2011, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
