WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

NGC 1333 IRAS 2A
RA: 3 28 55.6 (^{h m s})
Dec: 31 14 36.96 (^{o ' "})

Observation Details

OBSID: 1342203229
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: NGC1333 IRAS2A - Setting 7
Band: 3A
Herschel Operation Day: OD462
Integration Time: 798 sec
LO Frequency: 829.962 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-08-19
HSA Processing Date: 2014-07-23
WISH Processing Date: 2014-08-01
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.63
Beam Efficiency (2012) ⁽¹⁾: η=0.747
Position offset (x,y): (5.63023,1.90963) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0292	0.0387
continuum (K)	0.147	0.144

Downloads Corner

• RAW HIPE FORMAT (97MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Benz et al. 2015, A&A Submitted
Kristensen et al. 2013, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
