WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

NGC1333 IRAS4A
RA: 3 29 10.5 (^{h m s})
Dec: 31 13 31.08 (^{o ' "})

Observation Details

OBSID: 1342203951
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP2_H2O 212-101 - NGC1333 IRAS4A
Band: 6B
Herschel Operation Day: OD477
Integration Time: 1652 sec
LO Frequency: 1666.5615 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-09-03
HSA Processing Date: 2014-07-24
WISH Processing Date: 2014-08-22
Beam Efficiency H ⁽¹⁾: η=0.58
Beam Efficiency V⁽¹⁾: η=0.58
Beam Efficiency (2012) ⁽¹⁾: η=0.707
Position offset (x,y): (2.98863,2.345) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	No	No
Reso. (MHz)	1.1	0.125
	WBS-H	WBS-V
rms (K)	0.0289	0.0264
continuum (K)	0.061	0.064

Downloads Corner

• RAW HIPE FORMAT (101MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Benz et al. 2015, A&A Submitted
Mottram et al. 2014, A&A
Mottram et al. 2013, A&A
Kristensen et al. 2013, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
