WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

L 1448-r4
RA: 3 25 40.9 (^{h m s})
Dec: 30 41 60.00 (^{o ' "})

Observation Details

OBSID: 1342203953
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: L 1448 212 101 r4
Band: 6B
Herschel Operation Day: OD477
Integration Time: 1321 sec
LO Frequency: 1667.20275 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-09-03
HSA Processing Date: 2014-07-24
WISH Processing Date: 2014-08-04
Beam Efficiency H ⁽¹⁾: η=0.58
Beam Efficiency V⁽¹⁾: η=0.58
Beam Efficiency (2012) ⁽¹⁾: η=0.707
Position offset (x,y): (3.22292,1.32864) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	0.125
	WBS-H	WBS-V
rms (K)	0.2709	0.3005
continuum (K)	-0.282	0.069

Downloads Corner

• RAW HIPE FORMAT (107MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Santangelo et al. 2012, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
