WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

H2O-18 202-111 - NGC6334-I
RA: 17 20 55.2 (^{h m s})
Dec: -35 45 3.96 (^{o ' "})

Observation Details

OBSID: 1342204518
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: H2O-18 202-111 - NGC6334-I
Band: 4A
Herschel Operation Day: OD488
Integration Time: 553 sec
LO Frequency: 739.2465 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-09-14
HSA Processing Date: 2014-07-24
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.64
Beam Efficiency V⁽¹⁾: η=0.66
Beam Efficiency (2012) ⁽¹⁾: η=0.75
Position offset (x,y): (2.40705,-1.0538) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0735	0.0848
continuum (K)	2.661	2.455

Downloads Corner

• RAW HIPE FORMAT (106MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
