WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

NGC6334-I-1
RA: 17 20 53.3 (^{h m s})
Dec: -35 46 59.88 (^{o ' "})

Observation Details

OBSID: 1342205278
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: H2O 110-101Map - NGC6334-I-N-
Band: 1A
Herschel Operation Day: OD503
Integration Time: 158 sec
LO Frequency: 546.3405 GHz
HIPE/Pipeline Version: SPG v11.1.0
Observation Date: 2010-09-28
HSA Processing Date: 2014-01-30
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (2.44618,-1.01024) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.1266	0.0553
continuum (K)	1.227	1.282

Downloads Corner

• RAW HIPE FORMAT (91MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
