WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

Ser SMM1
RA: 18 29 49.7 (^{h m s})
Dec: 1 15 20.48 (^{o ' "})

Observation Details

OBSID: 1342207657
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: KPGT_evandish_1-H2O-18 202-111 - Ser SMM1
Band: 4A
Herschel Operation Day: OD533
Integration Time: 2300 sec
LO Frequency: 738.747 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-10-29
HSA Processing Date: 2014-07-24
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.64
Beam Efficiency V⁽¹⁾: η=0.66
Beam Efficiency (2012) ⁽¹⁾: η=0.75
Position offset (x,y): (-2.42601,-0.38636) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0285	0.0333
continuum (K)	0.383	0.451

Downloads Corner

• RAW HIPE FORMAT (121MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Mottram et al. 2014, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
