WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

Ser SMM4
RA: 18 29 56.6 (^{h m s})
Dec: 1 13 15.10 (^{o ' "})

Observation Details

OBSID: 1342208577
Obs. Type: HIFI Single Point
Obs. Mode: Position Switch
AOR Label: PSP1_H2O 110-101 - Ser SMM4
Band: 1B
Herschel Operation Day: OD534
Integration Time: 646 sec
LO Frequency: 562.58775 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-10-30
HSA Processing Date: 2014-07-25
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (-2.43352,-0.27967) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0147	0.0198
continuum (K)	0.076	0.109

Downloads Corner

• RAW HIPE FORMAT (183MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Mottram et al. 2014, A&A
Mottram et al. 2013, A&A
Kristensen et al. 2012, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
