Source Details

L723 MM
RA: 19 17 53.8 (^{h m s})
Dec: 19 12 20.16 (^{o ' "})

Observation Details

OBSID: 1342210154
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: KPGT_evandish_1-H2O 211-202 - L723 MM
Band: 2B
Herschel Operation Day: OD561
Integration Time: 946 sec
LO Frequency: 759.036 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2010-11-26
HSA Processing Date: 2014-07-25
WISH Processing Date: 2014-08-07
Beam Efficiency H ⁽¹⁾: η=0.64
Beam Efficiency V⁽¹⁾: η=0.66
Beam Efficiency (2012) ⁽¹⁾: η=0.749
Position offset (x,y): (-0.63535,-0.1513) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	Yes
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0305	0.0243
continuum (K)	0.008	0.004

Downloads Corner

• RAW HIPE FORMAT (103MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Mottram et al. 2014, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
