Source Details

IM Lup
RA: 15 56 9.1 (^{h m s})
Dec: -37 56 6.00 (^{o ' "})

Observation Details

OBSID: 1342214336
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP2_H2O 110-101 - IM Lup
Band: 1B
Herschel Operation Day: OD643
Integration Time: 2511 sec
LO Frequency: 564.7905 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2011-02-15
HSA Processing Date: 2014-07-30
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (2.06262,0.119075) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0066	0.0087
continuum (K)	0.005	0.010

Downloads Corner

• RAW HIPE FORMAT (122MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
