WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

R CrA IRS 5
RA: 19 1 48.0 (^{h m s})
Dec: -36 57 21.60 (^{o ' "})

Observation Details

OBSID: 1342215840
Obs. Type: HIFI Single Point
Obs. Mode: Position Switch
AOR Label: PSP2_H2O 110-101 Class I - R CrA IRS 5
Band: 1B
Herschel Operation Day: OD666
Integration Time: 1190 sec
LO Frequency: 562.66425 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2011-03-10
HSA Processing Date: 2014-07-31
WISH Processing Date: 2014-08-05
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (2.07518,-0.13982) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0278	0.0281
continuum (K)	0.071	0.056

Downloads Corner

• RAW HIPE FORMAT (212MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Schmalzl et al. 2014, A&A
Mottram et al. 2014, A&A
Kristensen et al. 2012, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
