WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

L483 MM-b
RA: 18 17 27.1 (^{h m s})
Dec: -4 39 38.99 (^{o ' "})

Observation Details

OBSID: 1342217692
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: PSP2_L483 MM-blue
Band: 1B
Herschel Operation Day: OD688
Integration Time: 328 sec
LO Frequency: 564.64425 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2011-04-02
HSA Processing Date: 2014-07-31
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (-2.33455,0.696764) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0187	0.0215
continuum (K)	0.020	0.022

Downloads Corner

• RAW HIPE FORMAT (98MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Tafalla et al. 2013, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
