WISH Live Data Show 2.0

WISH PROPRIETARY DATA ©

Source Details

L723 MM
RA: 19 17 53.8 (^{h m s})
Dec: 19 12 20.16 (^{o ' "})

Observation Details

OBSID: 1342219172
Obs. Type: HIFI Single Point
Obs. Mode: DBS fastChop
AOR Label: KPGT_evandish_1-H2O-18 110-101 - L723 MM - resched
Band: 1A
Herschel Operation Day: OD707
Integration Time: 2069 sec
LO Frequency: 542.42325 GHz
HIPE/Pipeline Version: SPG v12.1.0
Observation Date: 2011-04-21
HSA Processing Date: 2014-08-01
WISH Processing Date: 2014-08-02
Beam Efficiency H ⁽¹⁾: η=0.62
Beam Efficiency V⁽¹⁾: η=0.62
Beam Efficiency (2012) ⁽¹⁾: η=0.754
Position offset (x,y): (-1.1185,0.379707) arcsec

Spectral Details

	WBS	HRS
FitBaseline	Yes	No
FitHifiFringe	Yes	No
Reso. (MHz)	1.1	1.1
	WBS-H	WBS-V
rms (K)	0.0057	0.0057
continuum (K)	0.015	0.017

Downloads Corner

• RAW HIPE FORMAT (116MB)
• FITS FORMAT
• CLASS FORMAT

Publications

This data was published in:
Visser et al. 2015, A&A
Mottram et al. 2014, A&A
Yildiz et al. 2013A, A&A
San Jose-Garcia et al. 2013, A&A

Notes
⁽¹⁾ The observation files (HIPE, CLASS and fits formats) were reduced with the old Beam Efficiencies published in Roelfsema et al. 2012. New beam efficiencies are given as H and V separately. Please correct for new beam efficiency before analysis.
